Elektor Six Digit Nixie Clock (150189-71)

I built the clock and made one stupid mistake. I failed to ensure the nixies were snugly seated on the back board before soldering them. They are a little bit cock eyed. To fix them would require some really serious custom building of esoteric soldering hardware and the risk of damaging the nixies.

"Perfection is the Enemy of Good Enough. " we concluded.

I found it very difficult to solder the GPS daughter board since my eye sight isn't so good. LED 1 isn't going out and the 00:00:00 display isn't locking into a valid clock data stream.

"Once data is received, the microcontroller checks whether it is a GPS string and then writes the entire string to memory after a carriage return (CR) character is received. Then the checksum
of the received string is calculated and compared to the checksum in the string.
If the checksums match, the data is considered valid.

The GPS data acquisition process starts with the GPS string GPRMC output by the GPS module. The
initialization routine configures the module to send this string, all by itself, once per second. All other
GPS strings are disabled. The microcontroller polls the RS232 receive buffer to check for new
data. The internal watchdog keeps an eye on this, and if the RS232 data stream does not start
flowing after startup, it resets the microcontroller after about 1 minute. LED1 is lit during this 1-minute interval. Once a valid string is received, the RS232 data line is still monitored but in a different manner. Here again, if the LED is constantly lit there is a problem."


Most likely diagnosis is that the soldering isnt providing appropriate or contiguous connection.  Also possible the GPS unit was traumatized by the mounting / installation process.

First step will be to meter out the solder joins for continuity.

UPDATE: Sure enough James and I metered it out (after James filed a wickedly sharp point on the meter probes.) There was a bridge on one of the solder joins  - 0.00 Ohms on two leads VS nominal resistance .5 - 1 meg. Once the flux had been cleaned off, it was possible for me to see it with 4.5 reading glasses. James was able to see it through the unsullied eyes of unaided rude youth and innocence. Required a robust application of heat on a triangle of solder wick to get the excess off. Bover Boy Bolton on the Iron. Young James on Rimshot.

Then it started to work. "Boom Tish."

It was good fun fault finding with MOM James as ever.
